TECHNICAL DATA
| Connector system | Φ2.5mm; Φ4mm; Φ6mm；Φ10mm |
| Rated voltage | 1000V DC |
| Rated current | 30A(2.5mm2;4mm2; 6mm2; 14AWG; 12AWG; 10AWG) 45A(4mm2; 6mm2; 12AWG;10AWG) |
| Test voltage | 6kV(50HZ,1min.) |
| Ambient temperature range | -40℃ ...+90℃ (IEC) -40℃ ...+75℃ (UL) |
| Upper limiting temper ature | +105℃ (IEC) |
| Degree of protection,mated | IP67 |
| unmated | IP2X |
| Comtact resistanceof plug connectors | 0.5mΩ |
| Safetyclass | Ⅱ |
| Contact material | Messing,verzinnt Copper Alloy,tin plated |
| Insulation material | PC/PPO |
| Locking system | Snap-in |
| Flame class | UL-94-Vo |
| Salt mist spray test,degree of severity 5 | IEC 60068-2-52 |
